VIPER27LDTR Converter Offline Flyback Topology 60kHz 16-SO 800V 20 W

Description

The device is an off-line converter with an 800 V rugged power section, a PWM control, two levels of over-current protection, overvoltage and overload protections, hysteretic thermal protection, soft-start and safe auto-restart after any fault condition removal. Burst mode operation and device very low consumption help to meet the standby energy saving regulations.

Advance frequency jittering reduces EMI filter cost. Brown-out function protects the switch mode power supply when the rectified input voltage level is below the normal minimum level specified for the system. The high voltage start-up circuit is embedded in the device.

Features

■ 800 V avalanche rugged power section

■ PWM operation with frequency jittering for low EMI

■ Operating frequency: – 60 kHz for L type – 115 kHz for H type

■ Standby power < 50 mW at 265 Vac

■ Limiting current with adjustable set point

■ Adjustable and accurate overvoltage protection

■ On-board soft-start

■ Safe auto-restart after a fault condition

■ Hysteretic thermal shutdown

Application

■ Auxiliary power supply for consumer and home equipments

■ ATX auxiliary power supply

■ Low / medium power AC-DC adapters

■ SMPS for set-top boxes, DVD players and recorders, white goods
